Table D-6 (Cont.) Replacement Parts for Sun ZFS Storage 7320 appliance
Part
Number
Description Coverage
under Basic
Warranty
7042768 500GB 10K 2.5 inch SATA HDD (Silver Marlin Bracket, OS
drive)
FRU
F542-0330 512GB SSD, 2.5" SATA Marlin bracket (ReadZilla) (FW-
AGXA0201)
FRU
F375-3609 8 Port LSI SAS-2 6G HBA FRU
F375-3606 Dual port 4X QDR InfiniBand PCI-E HCA (CX1) FRU
F511-1496 Generation 2 Cluster Heatbeat PCI-E Card FRU
F300-2233 PS,AC,A247,F,12V,760W FRU
F541-2732 DVD Drive Bay Panel FRU
For more information, see the Sun ZFS Storage 7x20 Appliance Customer Service Manual.
D.7 Parts for Oracle Server X5-2 Compute Nodes
Table D-7 lists the replaceable parts for the Oracle Server X5-2 compute nodes used in
the Exalogic machine.
Note:
All replacement parts shown in the following table are considered FRU when
covered under Premier Support of Systems warranty.
Table D-7 Replacement Parts for Oracle Server X5-2 Compute Nodes
Part Number Description Coverage with
Basic Warranty
7089073 FAN MODULE FRU
7094132 SSD, 400GB ME, 2.5" SAS3, Marlin FRU
7078072 DIMM, 32GB, DDR3, 1600, 4Rx4, 1.35V FRU
7067728 HEAT SINK CPU 1U FRU
7095106 CPU, E5-2699, 2.3G, 145W, 18C FRU
7097205 ASSY, 2.5 DISK BP FRU
7085209 ASY, 12G SAS RAID HBA, INT, 8P FRU
7083433 ASSY, RISER, DOUBLE_STACK FRU
7083430 ASSY, RISER FRU
Parts for Oracle Server X5-2 Compute Nodes
Replacement Units D-7
