This section contains the following topics for Three Phase PDUs:
• Three Phase PDU Power Cabling Full Rack
• Three Phase PDU Power Cabling Half Rack
• Three Phase PDU Power Cabling Quarter Rack
• Three Phase PDU Power Cabling Eighth Rack
E.3.1 Single Phase PDU Power Cabling Full Rack
This section contains the following tables:
• Table E-14
Table E-14 lists the location, ports and cables for the Single Phase PDU connections for
an Exalogic machine full rack.
Table E-14 Single Phase PDU Power Cabling for Exalogic Machine Full Rack
From Rack
Unit
Type of Equipment PDU-A PDU-B Jumper Length
U42 Compute node G5-5 G0-1 2M
U41 Compute node G5-4 G0-2 2M
U40 Compute node G5-3 G0-3 2M
U39 Compute node G5-2 G0-4 2M
U38 Compute node G5-1 G0-5 2M
U37 Compute node G5-0 G0-6 2M
U36 Compute node G4-6 G1-0 2M
U35 Compute node G4-5 G1-1 2M
U34 Compute node G4-4 G1-2 2M
U33 Compute node G4-3 G1-3 2M
U32 Compute node G4-2 G1-4 2M
U31 Compute node G3-6 G2-0 2M
U30 Compute node G3-5 G2-1 2M
U29 Compute node G3-4 G2-2 2M
U28 Compute node G3-3 G2-3 2M
U27 Compute node G3-2 G2-4 2M
U26 NM2-GW SW G4-0 G1-6 2M
U25 Cisco Switch G3-1 G2-5 2M
U24 NM2-GW SW G3-0 G2-6 2M
Power Distribution Unit Cabling Tables
Cabling Tables E-23
