Table E-11 InfiniBand Gateway Switch Inter-Connections for Exalogic Machine
Quarter Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U16 4A U23 Sun Network
QDR InfiniBand
Gateway Switch
4A 2 meter QDR
InfiniBand cable
U16 4B U23 Sun Network
QDR InfiniBand
Gateway Switch
4B 2 meter QDR
InfiniBand cable
U16 5A U23 Sun Network
QDR InfiniBand
Gateway Switch
5A 2 meter QDR
InfiniBand cable
U16 5B U23 Sun Network
QDR InfiniBand
Gateway Switch
5B 2 meter QDR
InfiniBand cable
U16 6A U23 Sun Network
QDR InfiniBand
Gateway Switch
6A 2 meter QDR
InfiniBand cable
U16 6B U23 Sun Network
QDR InfiniBand
Gateway Switch
6B 2 meter QDR
InfiniBand cable
E.2.4 Exalogic Machine Eighth Rack
This section contains the following tables:
• Table E-12
• Table E-13
Table E-12 lists the location, ports and cables for the InfiniBand connections for an
Exalogic machine eighth rack.
InfiniBand Network Cabling Tables
E-20 Oracle Exalogic Elastic Cloud Machine Owner's Guide
