Oracle Exalogic Elastic Cloud - Three Phase PDU Power Cabling Quarter Rack; Three Phase PDU Power Cabling for Exalogic Machine Half Rack

Table E-19 Three Phase PDU Power Cabling for Exalogic Machine Half Rack
From Rack
Unit
Type of Equipment PDU-A PDU-B Jumper Length
U28 Compute node G3-4 G0-2 2M
U27 Compute node G3-3 G0-3 2M
U25 Cisco Switch G3-1 G0-5 2M
U23 NM2-GW-SW G2-5 G5-1 2M
U22 ZS3-ES HN G3-0 G0-6 2M
U21 ZS3-ES HN G2-4 G5-2 2M
U17 DE2-24C DS G2-3 G5-3 1M
U16 NM2-GW-SW G1-6 G4-0 2M
U15 Compute node G2-2 G5-4 2M
U14 Compute node G2-1 G5-5 2M
U13 Compute node G2-0 G5-6 2M
U12 Compute node G1-4 G4-2 2M
U11 Compute node G1-3 G4-3 2M
U10 Compute node G1-2 G4-4 2M
U09 Compute node G1-1 G4-5 2M
U08 Compute node G1-0 G4-6 2M
U07 Compute node G0-6 G3-0 2M
U06 Compute node G0-5 G3-1 2M
U05 Compute node G0-4 G3-2 2M
U04 Compute node G0-3 G3-3 2M
U03 Compute node G0-2 G3-4 2M
U02 Compute node G0-1 G3-5 2M
U01 NM2-36P SW G0-0 G3-6 2M
E.3.7 Three Phase PDU Power Cabling Quarter Rack
This section contains the following tables:
• Table E-20
Table E-20 lists the location, ports and cables for the Three Phase PDU connections for
an Exalogic machine quarter rack.
Power Distribution Unit Cabling Tables
