Table D-8 (Cont.) Replacement Parts for Sun Server X4-2 Compute Nodes
Part Number Description Coverage with
Basic Warranty
7027478 ASSY, 2.5 DISK BP FRU
7018701 DIMM, 16GB, DDR3, 1600, 2Rx4, 1.35V FRU
7038488 FLASH DRIVE, TLC, OSA ID, USB, 4GB FRU
7047503 ASY, 6G SAS RAID HBA, INT, B4, 8P FRU
7057184 ASSY, MOUNT-BATTERY, REMOTE FRU
7077233 400 GB SSD in Marlin Brkt FRU
For more information, see the Sun Server X4-2 Service Manual.
D.9 Parts for Sun Server X3-2 Compute Nodes
Table D-9 lists the replaceable parts for the Sun Server X3-2 compute nodes used in the
Exalogic machine.
Note:
All replacement parts shown in the following table are considered FRU when
covered under Premier Support of Systems warranty.
Table D-9 Replacement Parts for Sun Server X3-2 Compute Nodes
Part Number Description Coverage with
Basic Warranty
7026878 1X 2.9 Ghz Intel 8-Core Xeon E5-2690, 135 W FRU
7020774 Heatsink, CPU, X4170 M3 FRU
7018701 16 GB DIMMs FRU
F375-3696 Dual port 4X QDR InfiniBand PCI-E HCA (CX2) FRU
F375-3701 6 GB/s SAS RAID HBA,Internal FRU
7105627 ASSY Battery Carrier Remote FRU
7106158 Universal Upgrade Remote Battery Kit FRU
542-0388 300 GB Disk FRU
7047410 A256 600 W AC Input Power Supply FRU
7048712 System Board Assembly FRU
7027478 4-Slot 2.5" Disk Backplane Assembly FRU
7048710 1 Slot PCI Express Riser Assembly FRU
Parts for Sun Server X3-2 Compute Nodes
Replacement Units D-9
