Table E-10 (Cont.) InfiniBand Network Cabling for Exalogic Machine Quarter Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U23 14B U4 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 15A U3 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 15B U2 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U16 8A U22 Storage appliance
server head
PCIe 0, P1 3 meter QDR
InfiniBand cable
U16 8B U21 Storage appliance
server head
PCIe 0, P1 3 meter QDR
InfiniBand cable
U16 12A U9 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U16 12B U8 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U16 13A U7 Compute node PCIe 2, P1 2 meter QDR
InfiniBand cable
U16 13B U6 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
U16 14A U5 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
U16 14B U4 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
U16 15A U3 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
U16 15B U2 Compute node PCIe 2, P1 3 meter QDR
InfiniBand cable
Table E-11 lists the InfiniBand gateway switch inter-connections for an Exalogic
machine quarter rack.
InfiniBand Network Cabling Tables
Cabling Tables E-19
