Table E-6 InfiniBand Gateway Switch Inter-Connections for Exalogic Machine Full
Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U16 4A U23 Sun Network
QDR InfiniBand
Gateway Switch
4A 2 meter QDR
InfiniBand cable
U16 4B U23 Sun Network
QDR InfiniBand
Gateway Switch
4B 2 meter QDR
InfiniBand cable
U16 5A U23 Sun Network
QDR InfiniBand
Gateway Switch
5A 2 meter QDR
InfiniBand cable
U16 5B U23 Sun Network
QDR InfiniBand
Gateway Switch
5B 2 meter QDR
InfiniBand cable
U16 6A U23 Sun Network
QDR InfiniBand
Gateway Switch
6A 2 meter QDR
InfiniBand cable
U16 6B U23 Sun Network
QDR InfiniBand
Gateway Switch
6B 2 meter QDR
InfiniBand cable
U24 4A U26 Sun Network
QDR InfiniBand
Gateway Switch
4A 1 meter QDR
InfiniBand cable
U24 4B U26 Sun Network
QDR InfiniBand
Gateway Switch
4B 1 meter QDR
InfiniBand cable
U24 5A U26 Sun Network
QDR InfiniBand
Gateway Switch
5A 1 meter QDR
InfiniBand cable
U24 5B U26 Sun Network
QDR InfiniBand
Gateway Switch
5B 1 meter QDR
InfiniBand cable
U24 6A U26 Sun Network
QDR InfiniBand
Gateway Switch
6A 1 meter QDR
InfiniBand cable
U24 6B U26 Sun Network
QDR InfiniBand
Gateway Switch
6B 1 meter QDR
InfiniBand cable
InfiniBand Network Cabling Tables
E-12 Oracle Exalogic Elastic Cloud Machine Owner's Guide
