Reracking Considerations Yes No N/A Comment
Is the clearance depth in the front of
the front mounting plane (distance to
the front cabinet door) at least 25.4
mm (1 inch)?
Does the target rack meet the
following minimum load capacity?
• 19kg/RU
• 785 kg total
Is the rack a four-post rack (mounting
at both front and rear).
Note: Two-post racks are not
compatible.
Does the target rack's horizontal
opening and unit vertical pitch
conform to ANSI/EIA 310-D-1992 or
IEC 60927 standards?
Does the target rack have RETMA
rail support?
Note: Exalogic racks require 19 inches
for RETMA rail spacing width. The
minimum rack width of 600 mm is
recommended to accommodate the
PDU and cable harnesses on the side.
If the rack is less than 600 mm wide,
then it must have additional depth to
accommodate mounting behind the
server CMAs.
Does the target rack support Oracle
cable management arms (CMAs)?
Does the target rack support
installation of Oracle vented and
solid filler panels?
Can the target rack provide tie-
downs along the left rear side of the
rack to support the InfiniBand cables?
The side is left rear side when viewed
from the front of the rack.
Can the target rack provide tie-
downs for the Ethernet wiring
harness?
Is there sufficient space for the cable
harnesses and the PDUs in the target
rack?
Can a label with the Exalogic rack
serial number be printed and
attached to the target rack?
Reracking Checklists
Site Checklists B-11
