Table 4-1 (Cont.) Default ILOM, NET0, and IB Bonded IP for Exalogic Full Rack
Unit Component (Front View) ILOM IP
Address
NET0 IP
Address
IB Bonded IP
Address
32 Compute Node 192.168.1.122 192.168.1.22 192.168.10.22
31 Compute Node 192.168.1.121 192.168.1.21 192.168.10.21
30 Compute Node 192.168.1.120 192.168.1.20 192.168.10.20
29 Compute Node 192.168.1.119 192.168.1.19 192.168.10.19
28 Compute Node 192.168.1.118 192.168.1.18 192.168.10.18
27 Compute Node 192.168.1.117 192.168.1.17 192.168.10.17
26 Sun Network QDR InfiniBand
Gateway Switch
192.168.1.204 Not
applicable
Not
applicable
25 Cisco Management Switch Not
applicable
192.168.1.200 Not
applicable
24 Sun Network QDR InfiniBand
Gateway Switch
192.168.1.203 Not
applicable
Not
applicable
23 Sun Network QDR InfiniBand
Gateway Switch
192.168.1.202 Not
applicable
Not
applicable
22 Server head for the storage appliance 192.168.1.116 192.168.1.16 192.168.10.16
21 Server head for the storage appliance 192.168.1.115 192.168.1.15 192.168.10.15
20 Disk storage tray for the storage
appliance
Not
applicable
Not
applicable
Not
applicable
19
18
17
16 Sun Network QDR InfiniBand
Gateway Switch
192.168.1.201 Not
applicable
Not
applicable
15 Compute Node 192.168.1.114 192.168.1.14 192.168.10.14
14 Compute Node 192.168.1.113 192.168.1.13 192.168.10.13
13 Compute Node 192.168.1.112 192.168.1.12 192.168.10.12
12 Compute Node 192.168.1.111 192.168.1.11 192.168.10.11
11 Compute Node 192.168.1.110 192.168.1.10 192.168.10.10
10 Compute Node 192.168.1.109 192.168.1.9 192.168.10.9
9 Compute Node 192.168.1.108 192.168.1.8 192.168.10.8
8 Compute Node 192.168.1.107 192.168.1.7 192.168.10.7
7 Compute Node 192.168.1.106 192.168.1.6 192.168.10.6
Exalogic Machine Full Rack
4-2 Oracle Exalogic Elastic Cloud Machine Owner's Guide
