Table 6-2 (Cont.) IP Address Requirements for Exalogic Machine
Type of
Exalogic
Machine
Management
Network
Requirements
Client Access Network
Requirements
InfiniBand Private
Network (IPoIB)
Requirements
half rack Minimum of 38 IP
addresses
• At least 2 IP
addresses per
management
network for
compute nodes:
1 IP address for
ILOM
1 IP address for
ETH0
• 2 IP addresses
per controller/
server heads in
the storage
appliance
• 1 IP address per
Sun Network
QDR InfiniBand
Gateway Switch
Same as above. Minimum of one
IP address per
bond per compute
node.
Exalogic machine
half rack contains
16 compute
nodes.
One compute
node can be a
member of only
one private
network of an
application
domain.
quarter
rack
Minimum of 22 IP
addresses
• At least 2 IP
addresses per
management
network for
compute nodes:
1 IP address for
ILOM
1 IP address for
ETH0
• 2 IP addresses
for controllers/
server heads in
the storage
appliance
• 1 IP address per
Sun Network
QDR InfiniBand
Gateway Switch
Same as above. Minimum of one
IP address per
bond per compute
node.
Exalogic machine
quarter rack
contains 8
compute nodes.
One compute
node can be a
member of only
one private
network of an
application
domain.
Network Connection and IP Address Requirements
Understand Network Requirements and Configuration 6-9
