Specifications
17-34
2nd axis information
Unit
memory no. (Hex)
Name Description
UM 00471 External terminal input monitor of 2nd axis Refer to the description for the 1st axis.
UM 00474 Deviation of 2nd axis Refer to the description for the 1st axis.
UM 00476 Pulse input value of 2nd axis Refer to the description for the 1st axis.
UM 00478
Implementation or implementation done table of
2nd axis
Refer to the description for the 1st axis.
UM 00479 Auxiliary output code of 2nd axis Refer to the description for the 1st axis.
UM 0047A Repeat count set value of 2nd axis Refer to the description for the 1st axis.
UM 0047B Repeat count current value of 2nd axis Refer to the description for the 1st axis.
UM 0047C
Current value of 2nd axis Refer to the description for the 1st axis.
UM 0047D
UM 0047E
Unit system conversion current value of 2nd axis Refer to the description for the 1st axis.
UM 0047F
3rd axis information
Unit
memory no. (Hex)
Name Description
UM 004B1 External terminal input monitor of 3rd axis Refer to the description for the 1st axis.
UM 004B4 Deviation of 3rd axis Refer to the description for the 1st axis.
UM 004B6 Pulse input value of 3rd axis Refer to the description for the 1st axis.
UM 004B8
Implementation or implementation done table of
3rd axis
Refer to the description for the 1st axis.
UM 004B9 Auxiliary output code of 3rd axis Refer to the description for the 1st axis.
UM 004BA Repeat count set value of 3rd axis Refer to the description for the 1st axis.
UM 004BB Repeat count current value of 3rd axis Refer to the description for the 1st axis.
UM 004BC
Current value of 3rd axis Refer to the description for the 1st axis.
UM 004BD
UM 004BE
Unit system conversion current value of 3rd axis Refer to the description for the 1st axis.
UM 004BF
