Panasonic FP7

Specifications
17-46
Offset address Name Default Setting range and description
02EH
− − −
02FH
− − −
030H
− − −
031H
− − −
032H
− − −
033H
Emergency
stop
deceleration
time
100
This parameter will be enabled if an emergency stop request is made with
I/O, and the deceleration of the positioning unit will be completed in the
specified deceleration time.
Setting range: 0 to 10,000 (ms)
Any other settings will be errors.
034H
− − −
035H
Limit stop
deceleration
time
100
This parameter will be enabled if limit input is ON while the positioning unit
is in operation, and the deceleration of the positioning unit will be
completed in the specified deceleration time.
Setting range: 0 to 10,000 (ms)
Any other settings will be errors.
036H
− − −
037H
Error stop
deceleration
time
100
This parameter will be enabled if an error occurs, and the deceleration of
the positioning unit will be completed in the specified deceleration time.
Setting range: 0 to 10,000 (ms)
Any other settings will be errors.
038H
Pulser
operation
setting code
0
If a pulse operation request is made with I/O, select the desired pulser
input from pulser inputs 1 to 4.
0: Pulser input 1
1: Pulser input 2
2: Pulser input 3
3: Pulser input 4
Any other settings will be errors.
039H
Pulser
operation ratio
numerator
1
Set a multiplier for the input pulse train for the operation of the pulser.
The number of reference pulses is obtained from the pulse train input from
the pulser multiplied by the numerator of the pulser operation
ratio/denominator of pulser operation ratio.
Setting range: 1 to 32,767
Any other settings will be errors.
03AH
Pulser
operation ratio
denominator
1
Set a divisor for the input pulse train for the operation of the pulser.
The number of reference pulses is obtained from the pulse train input from
the pulser multiplied by the numerator of the pulser operation
ratio/denominator of pulser operation ratio.
Setting range: 1 to 32,767
Any other settings will be errors.
