Specifications
17-50
Offset
address
Name Default Setting range and description
002H
− − −
003H
− − −
004H
Positioning
acceleration
time
100
The setting area for acceleration time and deceleration time for positioning
operation.
Different settings can be made for acceleration and deceleration.
The settings for the axis with the smallest number in the axis group are
enabled for interpolation operation.
Setting range: 0 to 10,000 (ms)
Any other settings will be errors.
005H
Positioning
deceleration
time
006H
Positioning
target speed
(Interpolation
speed)
1000
The target axis will operate at target speed in the case of single axis operation
and operate at target interpolation speed in the case of interpolation operation.
The settings for the axis with the smallest number in the axis group are
enabled for interpolation operation.
Setting range: 1 to 32,767,000
Any other settings will be errors.
Set the following range according to the unit setting.
Pulse: 1 to 32,767,000 pps
μm: 1 to 32,767,000 μm/s
inch: 0.001 to 32,767.000 inch/s
degree: 0.001 to 32,767.000 rev/s
007H
