LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
Code Service Code Description Corrective Action
1c05 Printer ADC out of tolerance (temperature) 1. Check the W14 Printer Flex Cable
2. Replace the A12 Printer
3. Replace the A05 UI PCB
1c06 Printer ADC out of tolerance (voltage) 1. Check the W14 Printer Flex Cable
2. Replace the A12 Printer
3. Replace the A05 UI PCB
1c07 UI voltage out of tolerance (5 V) Replace the A05 UI PCB
1c08 UI voltage out of tolerance (3.3 V) Replace the A05 UI PCB
1c09 UI voltage out of tolerance (2.5 V) Replace the A05 UI PCB
1c0a UI voltage out of tolerance (35 V) Replace the A05 UI PCB
1c0b UI voltage out of tolerance (SW VBATT) Replace the A05 UI PCB
1c0c UI voltage out of tolerance (ground) Replace the A05 UI PCB
1c0f UI hardware I.D. corrupted Replace the A05 UI PCB
1c10 UI boot program corrupted Replace the A05 UI PCB
(Continued on next page)
W14 Printer Flex Cable A12 Printer A05 UI PCB
