LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
A01 System PCB A05 UI PCB
Code Service Code Description Corrective Action
1c11 UI application Flash memory corrupted 1. Reload the device software*
2. Replace the A05 UI PCB
1c12 UI font Flash memory corrupted 1. Reload the device software*
2. Replace the A05 UI PCB
1c13 UI FPGA Flash memory corrupted 1. Reload the device software*
2. Replace the A05 UI PCB
1c16 UI CPU RAM test failed on power-on Replace the A05 UI PCB
1c17 UI CPU RAM test failed during normal operation Replace the A05 UI PCB
1fff Additional information related to error code that is
logged before 1fff
No action required; refer to error code logged
before 1fff.
2004 System cannot initialize serial port (system connector) Replace the A01 System PCB
2005 System cannot initialize driver for serial port (system
connector)
1. Reload the device software*
2. Replace the A01 System PCB
6-16
