LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
Code Service Code Description Corrective Action
5011 NVRAM configuration data error 1. Replace the coin cell battery
2. Reload the device software*
5012 Configuration data error Replace the coin cell battery
5013 System meter initialization error Reload the device software*
5014 System meter mismatch Replace the coin cell battery
5015 NVRAM error Replace the A01 System PCB
5016 MFG data mismatch Replace the A01 System PCB
5017 NVRAM MFG data lost Replace the A01 System PCB
5018 Watchdog reset failed Replace the A01 System PCB
5019 NVRAM corrupted Replace the coin cell battery
501a NVRAM corrupted Replace the coin cell battery
501c RTC not running 1. Replace the coin cell battery
2. Replace the A01 System PCB
(Continued on next page)
A01 System PCB Coin Battery
