LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
A04 Therapy PCB A01 System PCB A05 UI PCB A02 PP PCB W18 UI Flex Cable
Code Service Code Description Corrective Action
5029 Therapy USB did not initialize 1. Clear error and perform PIP
2. Replace the A04 Therapy PCB
502a UI USB did not initialize 1. Clear error and perform PIP
2. Replace the W18 UI Flex Cable
3. Replace the A05 UI PCB
502b USB system failed 1. Clear error and perform PIP
2. Replace the A01 System PCB
502f Device type invalid 1. Check configuration code
2. Set device type (software loader program)
3. Replace the A01 System PCB
5030 PP USB disconnect 1. Clear error and perform PIP
2. Replace the A02 PP PCB
5031 UI USB disconnect 1. Clear error and perform PIP
2. Replace the W18 UI Flex Cable
3. Replace the A05 UI PCB
6-24
