LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
(Continued on next page)
A01 System PCB
Code Service Code Description Corrective Action
6801 PP power supply out of tolerance Replace the A02 PP PCB
6802 PP pre-amp data invalid 1. Clear error and perform PIP
2. Replace the A02 PP PCB
6804 PP data RAM test error 1. Clear error and perform PIP
2. Replace the A02 PP PCB
6805 PP RAM test error 1. Clear error and perform PIP
2. Replace the A02 PP PCB
6806 PP CRC test error 1. Clear error and perform PIP
2. Replace the A02 PP PCB
6807 PP ECG test error 1. Clear error and perform PIP
2. Replace the A02 PP PCB
680b SpO2 board error Replace the A10 SpO2 Module
6fff Additional information related to error code that is logged
before 6fff
No action required for 6fff; refer to error logged
before 6fff.
6-31
