LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Front Case (continued)
A11 Active Display
Installation (continued)
14. Install four new 4-40 0.312 screws (173) to secure the display assembly to
the front case; torque to 6.8 in-lb.
15. Connect the W15 Active Display Cable to the A05 UI PCB at J36 (if removed
previously), as follows.
– Open the J36 connector lock.
– Insert the W15 Display Cable (metal contacts down) into the connector
lock.
– Close the connector lock to secure the cable.
Note: The cable connector must be square with the connector lock.
16. Complete the process by Installing the front case.
CAUTION
Possible component damage. The grounding harnesses must be installed at
precise angles to avoid damaging device components.
Parts List Interconnect Front Case View Rear View Main Assemblies
9-48
