1.11
GENERAL INFORMATION
1
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
MODEL: 2013 RANGER RZR 4 / EPS
MODEL NUMBER: R13XE76AD
MODEL NUMBER: R13XE7EAI
ENGINE NUMBER: 1204671
CLUTCH CHART
Engine
Platform
H.O. Domestic Twin
Cylinder,
Liquid Cooled, 4-Stroke
Engine Number 1204671 RZR800-13
Engine Displacement 760cc H.O.
Number of Cylinders 2
Bore & Stroke (mm) 80 x 76.5 mm
Compression Ratio 11:1
Compression Pressure 165 - 185 psi
Engine Idle Speed 1250 ± 100 RPM
Engine Max Operating RPM 6750 RPM
Lubrication Pressurized Wet Sump
Oil Requirements PS-4 Plus Synthetic
Oil Capacity 2 qts. / 1.9 liters
Coolant Capacity 5.5 qts. / 5.2 liters
Overheat Warning Instrument Cluster Indicator
Exhaust System
Dual Headpipe / Single Silencer
Fuel System
Fuel System Type Bosch M17 EFI
Fuel Delivery Electronic Fuel Pump (in tank)
Fuel Pressure 45 +/- 2 psi (310 +/- 14kPa)
Fuel Filters See Chapter 4
Fuel Capacity / Requirement
7.25 gal. (27.4 liters)
87 Octane (minimum)
Electrical
Alternator Max Output 500 Watts @ 3000 RPM
Headlights (Halogen) 2 - Halogen: Low 55 W / High 60 W
Headlights (LED)
2 - Dual Beam LED:
Low
27 Watts; High 40 Watts
Tail / Brake 2 - 6 Watts / 2 - 27 Watts
Starting System Electric Start
Ignition System Bosch M17 (ECU Controlled)
Ignition Timing (Variable) 3° - 10° BTDC @
1200 RPM
Spark plug / Gap RC7YC3 / .035 in. (0.9 mm)
Battery
Deka ETX30L / 30 AH
36
5 CCA / 12 Volt
Instrument Type Multifunction Instrument Cluster
DC Outlets (2) Standard 12 Volt
Relays
Chassis / EFI / Fan
Fuel
Pump / EPS
Circuit Breaker Fan Motor: 20 Amp
Fuses (Fuse/Relay Box)
Drive / Fuel Pump: 10 Amp
Li
ghts / EFI / Accessory: 20 Amp
Fuses (Power Fuse Holder)
EFI: 20 Amp
C
hassis / EPS: 30 Amp
Drivetrain
Transmission Type Polaris Automatic PVT
Drive Ratio - Front 3.82:1
Drive Ratio - Final 3.70:1
Shift Type In Line Shift - H / L / N / R / P
Front Gearcase
Fluid Type / Capacity
Polaris Demand Drive Plus
6.75 oz. (200 ml)
Transmission: Main Gearcase
Fluid Type / Capacity
Polaris AGL Plus
24 oz. (710 ml)
Transmission: Transfer Case
Fluid Type / Capacity
Polaris AGL Plus
14 oz. (414 ml)
Rear Gearcase
Fluid Type / Capacity
Polaris Premium ADF
26 oz. (769 ml)
Clutch Type Standard PVT
Drive Belt 3211133
Steering / Suspension
Front Suspension / Shock
Independent Dual A-arm
FOX™ 2.0 PODIUM Top Fill
FOX™ 2.0 PODIUM Piggyback
Front Travel 12 in. / 30.5 cm
Rear Suspension / Shock
Rolled IRS w/Anti-Sway Bar
FOX™ 2.0 PODIUM Top Fill
FOX™ 2.0 PODIUM Piggyback
Rear Travel 12 in. / 30.5 cm
Shock Preload Adjustment
Front / Rear
Threaded Spanner Wrench
Adjustment
Toe Out
1/8 - 1/4 in. (3 - 6.4 mm)
Wheels / Brakes
Front Wheel Type / Size Aluminum / 12 x 6
Rear Wheel Type / Size Aluminum / 12 x 8
Front Tire Type / Size
ITP “900XCT” / 27 x 9 R12
Maxxis Bighorn / 26 x 9 R12
Rear Tire Type / Size
ITP “900XCT” / 27 x 11 R12
Maxxis Bighorn / 26 x 12 R12
Tire Air Pressure
Front: 10 psi (69 kPa)
Rear: 12 psi (83 kPa)
Brake - Front / Rear
Foot Actuated - 4 Wheel
Hydraulic Disc
Brake Fluid DOT 4
Altitude
Shift
We
ight
Drive
Spring
Driven
Spring
Meters
(Feet)
0-1500
(0-5
000)
23-62
(5632337)
Green
(7043789)
Blk / Almond
(7043167)
1500-3700
(50
00 - 12000)
23-58 (B)
(1322911)
Green
(7043789)
Blk / Almond
(7043167)
PRELIMINARY VERSION
