10.26
ELECTRICAL
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
Relay Operation
Located in the fuse box under the dash, the relays assist
with component operation like the cooling fan, fuel pump
and EFI system, drive system and EPS.
NOTE: The Rear Diff Solenoid Relay is mounted
separately, attached to the rear plastic LH panel
divider behind the driver’s seat.
CHASSIS RELAY provides power to the following
systems:
• Lights (Headlights / Taillights)
• Drive (AWD / TURF)
• Accessory (12V Receptacles / Accessory Options)
EFI RELAY provides power to the following systems:
• Fuel Injectors
• Cam Phase Sensor
• Ignition Coil
• Fan Relay
• Fuel Pump Relay
FAN RELAY provides power to the following system:
•Fan Motor
FUEL PUMP RELAY provides power to the following
system:
•Fuel Pump
EPS RELAY provides power to the following system:
• Electronic Power Steering Unit
COLOR FUNCTION
Red
30-Amp fuse protected 12 Vdc
constant battery voltage.
Brown Relay coil ground.
Orange
12 Vdc power input from key
switch to enable relay.
White
Provides 12 Vdc power for lights,
drive and accessory circuits.
COLOR FUNCTION
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Dark Green / Yellow ECU ground input to enable relay.
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Red / Dark Blue
Provides 12 Vdc power for EFI
system circuits.
COLOR FUNCTION
Red
20-Amp circuit breaker protected
12 Vdc constant battery power.
Orange / White ECU ground input to enable relay.
Red / Dark Blue
12 Vdc switched power from EFI
relay.
Orange / Black
Provides 12 Vdc power for fan
operation.
COLOR FUNCTION
Red / Light Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green / Yellow ECU ground input to enable relay.
Red / Dark Blue
12 Vdc switched power from EFI
relay.
Red / Light Blue
Provides 12 Vdc power for fuel
pump operation.
COLOR FUNCTION
Red
30-Amp fuse protected 12 Vdc
constant battery voltage.
Brown Relay coil ground.
Orange
12 Vdc power input from key
switch to enable relay.
Orange
Provides 12 Vdc power for EPS
operation.
