10.27
ELECTRICAL
10
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
REAR DIFF SOLENOID RELAY (INT’L) provides power
to the following system:
• Rear Differential Solenoid
HEADLIGHT RELAY (INT’L) provides power to the
following systems:
• High Beam Headlights
• Low Beam Headlights
COLOR FUNCTION
Red / Dark Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green / White ECU input to enable relay.
Brown Relay coil ground.
Red
Relay switched power to operate
the Rear Diff Solenoid.
Blue
Ground to energize the Rear Diff
Solenoid.
COLOR FUNCTION
Red / Yellow
20-Amp fuse protected 12 Vdc
battery voltage.
White / Red Key switch input to enable relay.
Brown Relay coil ground.
Yellow / Dark Green
Relay switched power to operate
the Headlights.
