5.28
BODY / STEERING / SUSPENSION
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
ELECTRONIC POWER STEERING ASSEMBLY
Exploded View (EPS Models)
Power Steering
Unit
Nut
30 ft-lbs
(41 Nm)
Upper
Steering Shaft
Lower
Steering Shaft
15 ft-lbs
(20 Nm)
15-19 ft-lbs
(20-26 Nm)
Mounting
Bracket
20-24 ft-lbs
(27-33 Nm)
Boot
Rod End
Tie Rod
RH Boot
LH Boot
Spacer
Bearing
Steering
Cap
Pivot Tube
Cotter Pin
Gear Box
Bearing
Oil Locking
Shock Asm.
Asm.
17 ft-lbs
(23 Nm)
17 ft-lbs
(23 Nm)
12-14 ft-lbs
(16-19 Nm)
42.5 ft-lbs
(58 Nm)
42.5 ft-lbs
(58 Nm)
12-14 ft-lbs
(16-19 Nm)
25-31 ft-lbs
(34-42 Nm)
23 ft-lbs
(31 Nm)
23 ft-lbs
(31 Nm)
7 ft-lbs
(10 Nm)
12 ft-lbs
(16 Nm)
Bushing
Thick
Washer
Thin
Washer
Thick
Washers
Thin
Washer
Thin
Washer
Spacer
Wheel
Bushing
Pivot Tube
Screw
Steering
Lock
Collar
INT’L Models
PRELIMINARY VERSION
