3.18
ENGINE / COOLING
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
Engine Removal
Because of its design configuration and fastener torque
requirements, Polaris recommends removing the engine,
transmission and rear gearcase as one assembly. Use the
following procedure when engine removal is required.
IMPORTANT: Some engine repair procedures can be
pe
rformed without removing the engine assembly
from the vehicle. Refer to “Accessible Engine
Components” on Page 3.14 for further information.
NOTE: The use of an overhead or portable engine
ho
ist is the only recommended method for removing
and installing the engine / transmission / rear
gearcase assembly.
NOTE: Have an assistant help guide the engine in
a
nd out of the vehicle while using an engine hoist to
prevent personal injury or damage to vehicle
components.
1. If vehicle was recently operated, allow it to cool down
be
fore attempting to perform any work.
2. Clean work area.
3. Thoroughly clean the engine and chassis.
4. Drain appropriate lubricant(s):
• If servicing the engine, drain engine oil.
• If servicing the transmission, drain the lubricant
fr
om the main gearcase and transfer case.
• If servicing the rear gearcase, drain the gearcase
lubr
icant.
5. Remove the driver’s seat (see Chapter 5).
6. Disconnect (-) negative battery cable.
7. Remove the passenger seat(s) and remove the rear
se
rvice panel (see Chapter 5).
8. Remove the (2) screws (A) from the rear of the center
c
onsole (RZR / RZR S only).
9. Remove the rear seat base assembly from the
ve
hicle:
• RZ
R / RZR S: Remove the (2) fasteners (B) from
the rear seat base (as shown above).
• RZ
R 4: Remove the (2) fasteners and seat latch
plunger (C). Slide the rear seat base to the left and
remove it.
10. Remove the rear bumper, rear cargo box and box
su
pports from the vehicle (see Chapter 5).
WARNING
Always wear safety glasses and proper shop
clothing when performing the procedures in this
manual. Failing to do so may lead to possible
injury or death.
A
B
B
C
PRELIMINARY VERSION
