4.9
ELECTRONIC FUEL INJECTION
4
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
Fuel Line Removal / Installation
1. Place a shop towel around the fuel line to catch any
dripping fuel. Squeeze the connector tabs together
and push the locking slide back.
2. Pull on the fuel line for removal.
3. To install the line(s), verify the connections are clean
an
d free of debris.
4. Snap the fuel line back over the nipple and slide the
lo
cking mechanism back into place. Verify the
connector tabs snap back into place.
Squeeze Connector Tabs
Fuel Rail
