5.38
BODY / STEERING / SUSPENSION
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
FRONT STABILIZER BAR (RZR / RZR S INT’L)
Stabilizer Bar Linkage Removal
1. Elevate and safely support the front of the vehicle.
2. Remove the lower shock mounting fastener from the
u
pper A-arm on each side of the vehicle (see
“Exploded View”).
3. Remove the upper portion of the linkage from the
stabilizer bar on eac
h side of the vehicle (see
“Exploded View”):
• RZR: Rem
ove the nut and linkage bushings, and
remove the linkages from the vehicle.
• RZR S INT’L: Re
move the bolts that attach the
upper portion of the linkages to the stabilizer bar
clamps and remove the linkages from the vehicle.
4. Inspect the linkage assemblies for s
igns of excessive
wear or damage. Replace linkage assembly if
damaged.
5. Reverse the procedure for installation. Torque the
lin
kage fasteners to specification (see “Exploded
View”).
Stabilizer Bar Removal
1. If stabilizer bar linkages are installed:
• RZR: Rem
ove the nut and linkage bushings (see
“Exploded View”).
• RZR S INT’L: Re
move the bolts that attach the
upper portion of the linkages to the stabilizer bar
clamps (see “Exploded View”).
2. Remove the hood and front bumper (see “BODY
COMP
ONENT REMOVAL”).
3. Remove the (4) T30 Torx fasteners retaining the front
b
umper support to the frame.
NOTE: Properly support the bumper support and
wir
es that are attached.
4. Remove the (2) upper radiator retaining bolts.
5. Remove the (4) bolts retaining the lower radiator
mou
nt bracket and remove the bracket from the
frame.
6. Allow radiator to sag down to allow access to recovery
bottle retaining
screws and filler neck retaining
screws.
7. Remove retaining screws from recovery bottle and
filler nec
k. Allow the recovery bottle and filler neck to
hang down to access the (4) bolts retaining the upper
radiator mount bracket.
Main
Frame
Bumper
Support
T30
Screws
Nuts
To Next Page
