9.23
BRAKES
9
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
2. Install brake line banjo bolt and torque to specification.
3. Install the pad adjustment screw and turn until
stationa
ry pad contacts disc, then back off 1/2 turn.
4. Follow bleeding procedure outlined earlier in
this
chapter.
5. Install wheel and torque wheel nuts to specification.
NOTE: If new pads are inst
alled, refer to “REAR
BRAKE PADS - Brake Burnishing Procedure”.
= T
Wheel Nuts:
Steel Wheels: 27 ft-lbs (37 Nm)
Aluminum Wheels: 30 ft-lbs + 90° (1/4 turn)
15 ft-lbs
(21 Nm)
PRELIMINARY VERSION
