Polaris 2015 RZR 900 Service Manual

4.14
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
19.Reinstall the intake plenum assembly and fasten the
lower mount to the transmission mount bracket
15
.
NOTE: Be sure the lower air box post is placed
properly into the rubber grommet.
NOTE: Be sure the air box boots fully seat onto
the dual throttle body before tightening the hose
clamps
16
.
Hose Clamps:
35 in-lb (4 Nm)
Intake Plenum Mount Screw:
22 ft-lb (30 Nm)
20.Reinstall the breather into the air box and tighten the
hose clamps retaining the air box to the throttle body
assembly.
21.Reinstall the two screws retaining the air box
assembly.
22.Position the intake hose onto the air box and tighten
the hose clamp.
23.Reinstall the cargo box access panel.
FUEL SYSTEM
