27.Using a 15mm socket, remove the four bolts from the
left side
23
and two from the right side
24
, securing the
transmission to the engine.
28.Remove the two fasteners
25
attaching the rear
transmission mount bracket assembly to the frame.
Remove the fasteners
26
that attach the rear mount to
the transmission. Remove the mount assembly from
the vehicle.
29.Slide transmission towards the rear of the vehicle. Lift
and rotate the top of the transmission towards the left
side of the vehicle. With the help of an assistant,
remove transmission from the left rear wheel well
area.
NOTE: Remove the grease zerk from the left rear
upper control arm and the differential solenoid (if
equipped) if there is trouble removing the
transmission.
