6
6.33
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
REF. DESCRIPTION REF. DESCRIPTION
1.
Fill Plug
44.
Gear, Sector 16T
2.
Drain Plug, Magnetic
45.
Gear, Sector 31T
3.
Screw, M8 x 1.25 x 30
46.
Pawl, Detent
4.
Screw, M6 x 1 x 20
47.
Star, Detent
5
Screw, M8 x 50
48.
Plate, Park, 12-Face
6.
Screw, M6 x 1 x 40
49.
Shaft, Output 53T
7.
Screw, M6 x 1 x 18
50.
Shaft, Idler 29T
8.
Nut, NyLoc, M8 x 1.25
51.
Shaft, Reverse 29T
9.
Washer, Cup
52.
Shaft, Front Output
10. Washer 53.
Shaft, Input Helical
11. Washer 54. Bellcrank
12. Washer 55.
Collar, Shift
13.
Pin, Dowel
56.
Rail, Shift Shaft
14.
Pin, Spring
57.
Tube, Vent, 1/4 in.
15.
Retaining Ring, External
58.
Shift Dog, Park
16.
Snap Ring
59.
Gear, 44T
17.
Retaining Ring, External
60.
Fork, Shift
18.
Retaining Ring, External
61.
Sprocket, Reverse
19.
Retaining Ring, Internal
62.
Gear, Low
20.
Retaining Ring, External
63.
Engagement Dog, 6-Face
21.
Retaining Ring, External
64.
Gear, High
22.
Retaining Ring, External
65.
Shaft, Pinion 11T
23.
Retaining Ring, External
66.
Gear, 46T
24.
Washer, Thrust
67.
Gear, Snorkel 13T
25.
Washer, Thrust
68.
Shaft, Shift
26. Shim 69.
Weldment, Rear Mount Bracket
27. Shim 70.
Bracket, Rear Mount
28.
Bearing, Needle Cage
71.
Cover, Bearing, Center Drive
29.
Bearing, Ball
72.
Spacer
30.
Bearing, Ball
73.
Chain, Silent
31.
Bearing, Ball
74.
Switch, Rotary, 2-Pin
32.
Bearing, Ball
75.
O-Ring
33.
Bearing, Needle Cage
76.
O-Ring
34.
Bearing, Ball
77.
O-Ring
35.
Bearing, Ball
78.
Seal, Triple Lip
36.
Spring, Compression
79.
Seal, Dual Lip
37.
Spring, Compression
80.
Seal, Triple Lip
38.
Spring, Compression, Detent
81. N/A
39.
Tube, Snorkel
82.
Sensor, Speed
40.
Cover, Sector Gears
85.
Bearing, Ball
41.
Case, RH
86.
Spring, Wave
42.
Case, LH
88.
Bracket, Wire Harness
43.
Drum, Shift
89.
Collar Sleeve, Input Shaft
TRANSMISSION
