8.32
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
29.Remove BOC post.
30.Remove rebound valve stack.
NOTE: If you are not changing valve shims you
can zip tie the shims together, this will keep valve
shim stack in their assembled order.
31.Note the side of the piston as it comes off the shock
shaft. Compression side down.
32.Remove the piston bearing if it shows any signs of
damage or wear.
33.Remove piston O-ring.
34.Take note if you have a bleed shim when removing
compression valve stack .
35.Remove bearing assembly and bearing cap.
STEERING / SUSPENSION
