Polaris 2015 RZR 900 Service Manual

8.40
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
27.Install compression side valve stack.
NOTE: When installing bleed shim, ensure the
tab is lined up with compression port.
28.Install rebound valve stack with required top out
washer.
29.Apply a thin layer of float fluid to the threads, nut, or
BOC post and torque to 22 ft-lbs (30 Nm).
30.Install BOC post valving.
NOTE: Ensure retaining ring is fully installed and
secure.
31.Install BOC piston and retaining ring.
32.Apply Loctite® primer to the body cap threads.
STEERING / SUSPENSION
