8.44
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
57.Remove bleed screw and set IFP to the appropriate
height.
58.While holding the IFP, install bleed screw with O-ring
using a 9/16” open end wrench.
59.Install reservoir cap O-ring on cap and apply a thin
layer of shock oil to side and O-ring.
60.Install reservoir cap and retaining ring.
61.With shock shaft fully extended, charge reservoir to
the appropriate nitrogen pressure.
100 PSI (690 kPa)
62.Ensure rebound and compression adjuster are fully
functioning by hand actuating the shock absorber.
NOTE: Check for any leaks or faults in the shock
absorber’s functionality.
63.Tap body cap into position.
STEERING / SUSPENSION
