9.32
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
CAUTION
Always use new brake disc mounting bolts. The bolts
have a pre-applied locking agent which is destroyed
upon removal.
Brake Disc Mounting Bolts:
18 ft-lb (24 Nm)
6. Install wheel hub assembly, washers, and castle nut.
Torque castle nut to specification and install a new
cotter pin.
Rear Wheel Hub Castle Nut:
110 ft-lbs (149 Nm)
7. Install rear caliper (see Chapter 9 – REAR CALIPER
SERVICE, page ). Bleed the brake system. (See
Chapter 9 – BRAKE BLEEDING / FLUID CHANGE,
page 9.8.
8. Field test unit for proper braking action before putting
into service. Inspect for fluid leaks and firm brakes.
Make sure brakes do not drag when pedal is
released. If the brakes drag, re-check assembly and
installation.
BRAKE SYSTEM
