9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
4.43
DATA DISPLAY
ITEM
DEFINITION VALUE VALUE DESCRIPTION
RPM Limit
Indicates if the ECU
is currently limiting
RPM
Active
ECU is limiting the RPM
Inactive
ECU is not limiting RPM
Selected Gear
Indicates what gear
position the
transmission switch
is in
dependent on gear
selected
High, Low, Neutral, Reverse, Park
”–” or Null indicates no reading from the sensor /
stuck between gear positions
Spark Angle
Same as ignition
timing
— —
Start Enable Driver
ECU control of the
start solenoid
Active
ECU is grounding the start solenoid. Unit should
crank when key is turned to START
Inactive
ECU is not grounding the start solenoid
Target Idle RPM
RPM the ECU is
attempting to get to
varies
—
Throttle Body
Initialization –
Learning Success
Indicates if the ECU
has learned to
position of the ETC
Yes
The ECU successfully learned the position of the
ETC when the engine was started.
No
The ECU failed to learn the position of the ETC
when the engine was started. Check throttle body
and connections. Cycle the key switch.
Throttle Position
How far open the
throttle plate is
0–100%
At warm idle, this can range from 0–3%
Throttle Limp-home
Operation Condition
ETC error and ECU
is limiting speed
Yes
There is an error in the throttle control and the
vehicle is limiting
No
Normal Operation
Turf Mode Switch
Input
Input to ECU to
indicate if turf mode
is switch On or Off
Active
ECU receiving a signal that the AWD switch is in
Turf Mode
Inactive
ECU receiving signal that the AWD switch is in
AWD or 2WD mode
Vehicle Speed
How fast the
transmission output
is turning (calculated
to wheel speed)
varies
—
EFI / FUEL SYSTEM
