REAR BUMPER

1. Disconnect the harness connectors at the tail lights.

2. Remove the zip ties retaining the harness to the rear

bumper.

3. Remove the seven (two lower and five upper) T-27

Torx screws retaining rear bumper to the cargo box.

4. Remove rear bumper from vehicle.

HOOD AND FRONT BODY WORK

HOOD REMOVAL

1. To remove the hood, turn both 1/4 turn latches

disengage the rear portion of the hood.

2. Lift rear of hood and slide forward to disengage the

front tabs and remove the hood from the vehicle.

DASH REMOVAL

1. Remove the hood as previously described.

2. Remove the two T-40 Torx screws

retaining the

Upper Dash cover between the front fenders

3. Disconnect the instrument cluster, AWD switch,

headlight switch, and ignition switch. Note their

location and wire routing.

4. Remove the upper dash.

LOWER DASH REMOVAL

1. Remove the upper dash assembly

2. Back out the blue LED light from the lower dash.

3. Remove the two T-40 Torx screws retaining the dash

and the one T-40 retaining the back of the dash to the

bracket.

4. Remove the dash assembly from the vehicle.

NOTE

The lower dash is also held by clips. Pull the dash

straight out to disengage the clips..
