9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
11.13
INDICATOR LAMPS
q
Check Engine
This indicator appears if an EFI-related fault occurs. Do
not operate the vehicle if this warning appears. Serious
engine damage could result. Your authorized POLARIS
dealer can assist.
w
EPS Warning (if
equipped)
This indicator illuminates when a fault has occurred in the
EPS system. Your authorized POLARIS dealer can
assist. EPS operation is possible with key on/engine off
for up to 5 minutes.
e
Engine Hot
This lamp illuminates to indicate an overheated engine. If
the indicator flashes, a severe overheating condition
exists.
r
Neutral
This lamp illuminates when the transmission is in neutral
and the ignition key is in the ON position.
t
Helmet/Seat Belt
This lamp flashes for several seconds when the key is
turned to the ON position. The lamp is a reminder to wear
helmet and seat belt before operating.
y
High Beam
This lamp illuminates when the headlamp switch is set to
high beam.
u
Chassis Fault
If applicable.
i
Performance Limited
If applicable.
ELECTRICAL
