9.14
9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
SECONDARY HAND BRAKE (INT'L)
SECONDARY BRAKE SYSTEM OVERVIEW
NOTE
Using the secondary service brake is not as efficient as using the foot brake.
The secondary service brake
q
is an alternative hand-controlled hydraulic braking system. To apply the secondary
service brake, simply pull the lever upwards and hold. Release the lever when ready to release brake force. When
applied, the secondary service brake applies braking force to the rear wheel brake calipers only.
CAUTION
The secondary service brake is NOT a parking brake. There is no locking mechanism to hold the braking force. A
braking force is applied only when the lever is pulled upward.
BRAKE SYSTEM
