9.3
GENERAL INFORMATION
SPECIAL TOOLS
PART NUMBER
DESCRIPTION
2870975 Mity Vac™
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
BRAKE SYSTEM SPECIFICATIONS
Front Brake System
ITEM
STANDARD SERVICE LIMIT
Front Pad
Thickness
.296 ± .007″
(7.53 ± .19 mm)
.180″ (4.6 mm)
Front Disc
Thickness
.295 ± .008″
(7.5 ± .2 mm)
.268″ (6.8 mm)
Front Disc
Runout
– .010″ (0.25 mm)
Rear Brake System
ITEM
STANDARD SERVICE LIMIT
Rear Pad
Thickness
.296 ± .007″
(7.53 ± .19 mm)
.180″ (4.6 mm)
Rear Disc
Thickness
.295 ± .008″
(7.5 ± .2 mm)
.268″ (6.8 mm)
Rear Disc
Runout
– .010″ (0.25 mm)
BRAKE SYSTEM
