11
9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
11.61
MAIN HARNESS RETENTION LOCATIONS
FRONT
q
Zip Tie Retention Locations
The white tape on a harness signifies a retention point.
REAR
ELECTRICAL
