9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
2.33
TORQUE
Tensioner Mounting Bolts:
7 ft-lb (10 Nm)
7. Install the plunger bolt. Torque fastener to
specification.
TORQUE
Plunger Bolt:
15 ft-lb (20 Nm)
SPARK ARRESTOR
The spark arrestor should be periodically cleaned to
remove accumulated carbon. A plugged spark arrestor
will affect engine performance. Replace a cracked or
damaged spark arrestor before running the vehicle.
1. Remove the spark arrestor retaining fasteners
q
.
2. Remove the arrestor from the end of the muffler.
3. Use a non-synthetic brush to clean the screen
w
on
the arrestor. If necessary, blow debris from the screen
with compressed air.
4. Inspect the screen for wear and damage. Replace if
damaged.
5. Reinstall the spark arrestor. Torque fasteners to
specification.
TORQUE
Spark Arrestor Fasteners:
8 ft-lb (11 Nm)
MAINTENANCE
