9.16
9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
SECONDARY BRAKE FLUID RESERVOIR
The secondary brake fluid reservoir
q
may be found on
the engine side of the panel between the driver and the
engine. To reduce the possibility of air getting into the
brake system, the fluid level MUST be maintained
between the MAX and MIN marks
w
on the reservoir.
SECONDARY BRAKE MASTER CYLINDER
The secondary brake master cylinder
q
is located on the
engine side of the panel separating the passenger and
engine compartments. This master cylinder controls only
the rear brakes when the secondary brake lever is
pulled.
BRAKE SYSTEM
