4.14
9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
FUEL VENT LINE ROUTING
q
Hinge Clip
y
Vent Line Termination Fitting
w
Panduit Strap
u
Fuel Vent Line (180 cm)
NOTE
Be sure the vent line is routed properly and secured with cable tie(s). Check the fuel tank vent line for signs of
wear, deterioration or damage. Replace vent line if necessary.
Symptoms of a restricted fuel tank vent include the
following:
Collapsing fuel tank
Engine miss or hesitation
Loss of engine performance
High exhaust temperatures.
EFI / FUEL SYSTEM
