9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
SUSPENSION
SUSPENSION INSPECTION
q
Inspect all control arm bushings/bearings to make sure they are not broken, missing or extremely loose .
w
Check for damage/impact to all control arms and/or trailing arms and radius rods.
e
Inspect stabilizer bar and stabilizer bar bushings for damage/wear.
r
Ensure the shocks are not leaking oil. especially around the shock caps and shaft seals.
SUSPENSION LUBRICATION
Refer to Grease Lubrication Points, page 2.27 for
suspension lubrication.
NOTE
There are no grease fittings on the front control arm
pivot points or the rear trailing arms.
MAINTENANCE
