9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
1.21
ENGINE
Platform
Turbocharged., 4–Stroke,
DOHC
Engine Displacement
925cc
Number of Cylinders
2
Bore & Stroke 93 x 68 mm
Compression Ratio
9:1
Engine Idle Speed
1200 +/- 100 RPM
Engine Max Speed
8800 RPM
Valve Clearance (Intake) .006 ± .002" (0.15 ± 0.05 mm)
Valve Clearance (Exhaust) .010 ± .002" (0.25 ± 0.05 mm)
Engine Hot Light
Instrument Cluster Indicator
Lubrication
Wet Sump
Oil Requirements
PS-4 Full Synthetic 5W-50 or
PS-4 Extreme Duty Full
Synthetic 10W-50
Oil Capacity 2.75 qt (2.6 L)
Coolant Type
Polaris 50/50 Extended Life
Anti-freeze
Coolant Capacity 10.8 qt (10.22 L)
FUEL SYSTEM
Type Bosch ME17 EFI
Fuel Delivery Electronic Fuel Pump (in-tank)
Fuel Pressure 58 ± 2 PSI (400 ± 14 kPa)
Fuel Capacity /
Requirement
9.5 gal. (36 L)
91 Octane (minimum)
ELECTRICAL
Alternator Max Output 660 Watts @ 3000 RPM
Lights: Main Headlights Dual Beam LED cluster
Taillights 0.2 Watt LED cluster
Brake Lights 2.9 Watt LED cluster
Ignition System ME17 ECU
Spark Plug / Gap MR9F / 0.7–0.8 mm
Battery / Amp Hr 12v Flooded, 575 CCA / 44 A/hr
DC Outlet Standard 12 Volt
Relays Fan, EFI, Fuel Pump, Chassis,
EPS
Fuses
10A Accy
10A Drive
10A EFI
10A Fuel
10A Instr
10A Key
10A Lights
10A Term
10A Unsw
10A Water
25A EPS
30A Fan
DRIVETRAIN
Transmission Type
Polaris Automatic PVT
Shift Type
In Line Shift - P/ R / N / L / H
Front Gearcase Lubricant Demand Drive Fluid
Front Gearcase Capacity 8.5 oz (250 mL)
Transmission Lubricant
AGL Synthetic Gearcase
Lubricant
Transmission Capacity 64 oz (1900 mL)
STEERING / SUSPENSION
Toe Out 1/8 - 3/16″ (3.2 - 4.8 mm)
Front Suspension Independent Dual A-arm
FOX Internal Bypass 2.5″
Front Travel 16″ (40.6 cm)
Rear Suspension Independent Trailing Arm
FOX Internal Bypass 3.0″
Rear Travel 18″ (45.7 cm)
Spring Adjustment Threaded Spanner Wrench
Adjustment
WHEELS / BRAKES
Front Rim / Size Aluminum 14 x 6
Rear Rim / Size Aluminum 14 x 8
Front Tire Make / Model /
Size
Maxxis Bighorn
29 x 9 R14
Rear Tire Make / Model /
Size
Maxxis Bighorn
29 x 11 R14
Tire Air Pressure
Front 18 psi (125 kPa)
Rear 19 psi (130 kPa)
Brake System
4 Wheel Hydraulic
Front: Triple Bore Caliper
Rear – Double Bore Caliper
Brake Fluid DOT 4
2018 RZR XP TURBO CLUTCH CHART
MODEL ALTITUDE
SHIFT
WEIGHT
DRIVE
SPRING
DRIVEN
SPRING
2018
RZR XP
Turbo
0-1800 Meters
(0-6000 Feet)
W-31-70
(5140832)
Black
(7044762)
Black / white
lettering
(7044369)
1800-3700 Meters
(6000–12000 Feet)
W-31-64
(5141004)
GENERAL INFORMATION
1
