9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
© Copyright Polaris Industries Inc.
31.Remove negative spring assembly, bearing
assembly, and bumper.
32.With the shaft assembly placed in clamp block and
secured in vise, apply a sufficient amount of heat to
the eyelet with a propane torch to remove the eyelet
with the correct body cap socket.
33.Use a wire brush, heat, and a pick to remove any
Loctite residue left in the eyelet and shaft threads.
Clean thoroughly with contact cleaner and lint-free
towel.
34.Apply Loctite primer 7649 to eyelet threads
q
. Wipe
over-spray off any external surface.
35.Remove all seals and o-rings from bearing assembly.
NOTE
If the DU bearing needs replacement, replace the
complete bearing assembly.
36.Clean all surfaces of the bearing housing and cinch
ring.
STEERING / SUSPENSION
