Chapter 2: Troubleshooting Your Library
Interpreting LEDs
96 Quantum Scalar i6000 User’s Guide
Note: The blinking codes described in Tab l e 10 on page 98 are the
same for Fibre Channel and SCSI drives in the UDS-2 drive sleds.
Figure 24 shows the locations of the status LEDs and the Fibre Channel
link LED on the rear of a UDS-2 drive sled.
Figure 24 Rear View of Fibre
Channel Drive Sled (UDS-2)
Figure 25 shows the locations of the status LEDs and the Fibre Channel
link LED on the rear of a UDS-3 drive sled.
FC link LED
fibre port
- top = blue
- middle = amber
- bottom = green
status LEDs:
