Chapter 15: Maintaining Your Library
Maintenance Actions
Quantum Scalar i6000 User’s Guide 641
Figure 74 Get/Put Graphical
Report
Scan Fiducials
The Scan Fiducials graphical report shows the results for tests of the
fiducial barcode on each tape magazine and drive sled, including the
width, expected Y position (shift), and the number of hits the scanner
receives while traveling up and down. (Only known magazines are
tested.)
• If the graphical report shows a failed result for one or more tape
magazines, replace the affected magazines.
