Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL DA-91I RFL Electronics Inc.
March 6, 2002 13 (973) 334-3100
“S” CODES
“S” codes appear in response to a “STATUS?” query. There are two “S” codes for the RFL DA-91I
when operated in a T1 or E1 system: S1 and S2. Like the “P” code, this number is displayed in both
decimal and binary form.
A typical response to a “STATUS?” query looks like this:
* OK
CHANNEL CARD 3, TYPE 126
S01 = 3 (B00000011)
S02 = 15 (B00001111);
Table 5. Remote status messages (“S” codes) for a T1 or E1 system
S CODE Position Value Description
S1 B 0 0 0 0 0 0 0 0 0 T1 system
- - - - - - - ↑
1 E1 system
B 0 0 0 0 0 0 0 0 0 Configuration OK
- - - - - - ↑ - 1 Bad Configuration
B 0 0 0 0 0 0 0 0 0 Remote Loopback OFF
- - - - -
↑ - -
1 Remote Loopback ON
B 0 0 0 0 0 0 0 0 0 Local Loopback OFF
- - - -
↑ - - -
1 Local Loopback ON
B 0 0 0 0 0 0 0 0 0 Service OFF
- - - ↑ - - - -
1 Service ON
S2 B 0 0 0 0 0 0 0 0 0 No Tx Activity
- - - - ↑ ↑ ↑ ↑
1 Tx activity on selected channel (See Table 6)
B 0 0 0 0 0 0 0 0 0 No Rx Activity
↑ ↑ ↑ ↑ - - - -
1 Rx activity on selected channel (See Table 6)
Table 6. Tx/Rx Activity
TX_ACT1 → TXD1
RX_
ACT1 → RXD1
TX_ACT2 → TXD2 RX_ACT2 → RXD2
TX_ACT3 → RTS1 RX_ACT3 → RLSD1
TX_ACT4 → RTS2 RX_ACT4 → RLSD2
