S Code Bits Used Value Description
S02(CH1)
S03(CH2)
S04(CH3)
S05(CH4)
B00000000
↑-------
0
Channel has valid timeslot setting.
1
Channel has invalid timeslot setting.
B00000000
-↑------
0
Channel timeslot bit allocation is OK
1
Channel timeslot bit allocation overflow
B00000000
--↑-----
0
Channel TX in data – not active
1
Channel TX in data – active
B00000000
---↑----
0
Channel RX out data – not active
1
Channel RX out data – active
B00000000
----↑---
0
Channel remote loopback – not active
1
Channel remote loopback – active
B00000000
-----↑--
0
Channel local loopback – not active
1
Channel local loopback – active
B00000000
------↑-
0
V.110 frame not OK
1
V.110 frame OK
B00000000
-------↑
0
Channel service OFF
1
Channel service ON
S06
B00000000
--↑-----
0
Ch. 1 and Ch. 2 no bit overlap
1
Ch. 1 and Ch. 2 bit overlap
